Electric hoist NINJA 400 12V
Latest addition to the Warrior Range. High Quality three stage planetary gearing ensure this is one of the quietest and smoothest winches on the market. The silky smooth performance and the full load holding brake make the C4500EWX the perfect solution for high spec appliations.
Outstanding Features:
Outstanding Features:
- Rated Line Pull: 4,500lb (2,043kg)
- Rope: 14,5m Length Ø6,4mm Stahlseil with Hook
- Motor: 1.95hp/1.37kw Fully Sealed Permanent Magnet Motor
- Heavy Duty Waterproof Contactors
- Double Sealed Drum
- Gear: 3-stage Planetary Metal Drivetrain
- Gear Ratio: 172:1
- Brake: automatic Mechanical Brake
- Lifetime Mechanical Warranty
- 3 Year Electric Warranty
Standard Accessories:
- 10ft Remote Handset
- 4-way-Roller-Fairlead
- Flat Mount Plate
- Hook 3/8
- Manual
- Mounting Plate: included
Further Information:
- Dimensions (L x B x H): 360mm x 126mm x 165mm
- Mounting Pattern: 129mm x 96mm
- App. Weight: 13kg
| Layer of | Line Pull |
| Synth. Rope | lbs/kg |
| 1 | 4500/2043 |
| 2 | 3642/1652 |
| 3 | 3060/1388 |
| Line Pull | Line Speed | Amp Draw | |
| lbs/kg | ft/min | m/min | 12 V |
| 0 | 11.6 | 3.6 | 20 |
| 1500/680 | 9.2 | 2.8 | 70 |
| 2500/1134 | 7.8 | 2.4 | 100 |
| 3500/1587 | 6.6 | 2.0 | 140 |
| Shipping weight: | 14,00 Kg |
| Product weight: | 13,00 Kg |
